5g HAKRC 7133 50A 2-6S Brushless ESC Mini Size Built-in Current Sensor Support Telemetry for DIY Freestyle RC FPV Racing Drone
40,92 €
- Description
- Additional information
- Reviews (0)
- Vendor Details
- Product Inquiry
Description
Notice: Only include ESC. Not include motor, flight controller, BEC showed in diagram picture.
ESC Specifications:
Input voltage: 2-6S Lipo
Continuous current: 50A
Peak current: 55A
Current ratio: 300
Quantity: 1PC
Size: 14x33mm
Product Net weight: 5g
ESC firmware: HAKRC_G071-2023_Multi_32_9.Hex
Protocol support: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
Features:
1. PCB adopts high-end 8-layer 3oZ thickened copper skin and double pad design, which has stronger over-current capability and good heat dissipation.
2. MOS adopts imported 40V high current resistance MOS, which has long life and strong load capacity.
3. High density and compact, with built-in galvanometer and programmable LED lights, small size, high integration, simple installation and reasonable wiring.
4. Use industrial grade LDO, resistant to high temperatures.
5. Use high-quality Japanese Murata capacitors with strong filtering performance.
6. Supports image transmission of ESC telemetry data.
High quality hardware:
The STM32G071G8U6 main control chip runs at a frequency of up to 64MHz. Using three-in-one IC driver and high-frequency ceramic capacitor. High-precision PCB production process, the pads are all metalized to prevent the pads from falling off during use; 3 ounces of copper thickness, 8-layer board, greatly reduces heat generation, thereby improving efficiency.
Hardware: PWM, Damped Light
Hardware PWM drive, smooth throttle response, Damped Light technology, and regenerative braking function make the motor decelerate sensitively and effectively, with precise control; active freewheeling technology extends the endurance time;
Package Included:
1x HAKRC 7133 50A ESC
Additional information
| Weight | 0,007 kg |
|---|
